XulfiqarSenior PakWheeler
Posts: 42280Joined: Aug 2003
May '22

This thread is being made in hope that people who have such information for their specific cars can provide this information from their owners manuals, This is to help those guys who either dont have the manuals and have a hard time finding this information,

e.g.

Engine oil fill capacity
Automatic Transmission oil capacity and type both dry fill and pan exchange if possible
Manual Transmission oil type and capacity
Differential(s) oil types and capacity
Coolant capacity and type
A/C refrigerant type and capacity (if possible, this is usually on a sticker in the engine room)

I understand this is duplicating the workshop manual thread, but this is to provide a quick glance system for this information for the persons who dont have this information and dont want to rely on hearsay or guesswork of mechanics.

  • created

    May '22

  • last reply

    Jul '23
  • 21

    replies

  • 5.8k

    views

  • 11

    users

  • 38

    likes

  • 15

    links

pinned May 31, '22

capsatومن شر حاسد إذا حسد
Posts: 30816Joined: Apr 2006
Jun '22

To begin with here is complete data (link)26 for 2UZ-FE.

will only share links

  • i will not post screen captures or pages from manual
    we shall post links so reading & effort to search habit grows
1 month later
pwuser162557941033Integrale
Posts: 778Joined: Jul 2021
Jul '22
15

For Suzuki Jimny JA11 F6A 660cc Turbocharged

Engine Oil: SAE 10W-30 API SF
Quantity: 3.2L with filter, 2.9L excluding filter
Change Interval: 5,000km or 6 months

Oil Filter P/N: 16510-81402

Alternatives: JS Asakashi C932J, ViC C-932, Donaldson P502024, Mann W67/2, Fleetguard LF3614, ViC C-110, Hengst H97W13

Spark Plug: NGK BPR5E (on sticker under hood)
Thread 14.0mm, Reach 19.0mm, Gap 0.8-0.9mm, Heat Range 5 (NGK spec)
For NGK plugs, BKR = BCPR manufactured to ISO standards.

Transmission Oil (5MT): SAE 90 GL-4 (SAE 75W-85 for cold regions)
Quantity: 1.2L drained (spec - DO NOT OVERFILL TO 2 LITERS! Speaking from personal experience.)
Change Interval: 20,000km or 2 years

Transfer Case Oil: SAE 90 GL-4 (SAE 75W-85 for cold regions)
Quantity: 0.8L
Change Interval: 20,000km or 2 years

Front and Rear Differential Oil: SAE 90 GL-5 (SAE 75W-85 for cold regions)
Quantity: 1.5L
Change Interval: 20,000km or 2 years

Fuel tank capacity: 40L

Refrigerant: R134a
Compressor Oil: RG-20, 80mL

Brake Fluid: DOT-3

pwuser162557941033Integrale
Posts: 778Joined: Jul 2021
Jul '22
4

For Daihatsu Mira / Toyota Pixis Epoch / Subaru Pleo DBA-LA300S-GBPF (Introduced 2011)
KF-VE3 DOHC D-VVT 660cc Naturally Aspirated
Taken from my prior research in my old thread here.6

Severe replacement conditions:
20,000km/year or more yearly mileage
Frequent short-distance trips (<8km)
Temperatures below 0°C

Engine Oil: SAE 0W-20 or 5W-30, API SM or greater
Quantity: 2.9L with filter, 2.7L excluding filter
OEM Change Interval: 10,000km (5,000km in severe conditions) or 6 months

Spark Plug: NGK SILKR6D10G
Thread 26.5mm, Reach 12.0mm, Gap 1.0mm, Heat Range 6 (NGK spec)

Transmission Fluid: Daihatsu AMMIX CVT Fluid DFE / DC
Quantity: 2.4L drained, 5.7L dry fill.
Change Interval: 50,000km

Transfer Case Oil: Daihatsu AMMIX Hypoid Gear Oil SAE 80W-90, API GL-5
Quantity: 0.57L
Change Interval: 100,000km

Fuel tank capacity: 30L (2WD) / 34L (4WD)

Coolant: Daihatsu AMMIX Long Life Coolant (pink) at 30% concentration (50% for cold regions)
Quantity: 3.2L total
Change Interval: First time every three years, then every two years

Windshield Washer Fluid Capacity: 1.5L

Brake Fluid: DOT-3

pinned Jul 22, '22

4 months later
XulfiqarSenior PakWheeler
Posts: 42280Joined: Aug 2003
Dec '22

One thing a lot of folks get wrong with the coolant is that the total is written including the reservoir to full mark.

In khyber case, the reservoir holds 300 ml or so and the engine holds 4000 ml

So when refilling with concentrate, one has to take that into consideration.

ADVERTISEMENT

1 month later

split this topic Feb 2, '23

A post was merged into an existing topic: Lubricant Discussion- Engine Oil / Gear Oil

23 days later
gohar83Gohar Hayat
Posts: 234Joined: Mar 2019
Feb '23

Toyota Land Cruiser 100 Series HDJ101 (1998-2007)

1HD-FTE, 4.2l inline-6 cylinder turbodiesel

Fuel: 50 cetane number
Capacity: 96L

Engine Oil: API CF-4, ACEA B3-96 or G-DLD-1
Quantity: 11.4L with oil filter, 10.1L without oil filter

Automatic Transmission Fluid:
4 speed (A442F): ATF D-II or Dexron-Il
Quantity: 6L (drain & refill)

5 speed (A750F): Toyota ATF WS
Quantity: 3L (drain & refill)

Coolant capacity 4 speed (A442F):
w/o Viscous heater: 12.8L
w/ Viscous heater: 13.3L

Coolant capacity 5 speed (A750F):
w/o Rear or Power heater: 12.8L
w/ Rear heater: 13.3L
w/ Power heater: 13.8L

Transfer case: API GL-4 or GL-5, SAE 75W90
Quantity: 1.3L

Front Differential: API GL-5 Hypoid gear oil, SAE 80W90
Quantity: 1.6L

Rear Differential: API GL-5 Hypoid gear oil, SAE 80W90
(with LSD, use LSD oil only)
Capacity: 3.2L (w/ diff lock), 3.3L (w/o diff lock)

Power steering fluid: ATF Dexron-II
Capacity: 0.8L

Front drive shaft thrust bearings: Synthetic oil & lithium soap base chassis grease, NLGI-1

Propeller shaft: Lithium-base multi-purpose, NLGI-2

Wheel bearing grease: Lithium-base multi-purpose, NLGI-2

Brake fluid: SAE J1703 or FMVSS 116 DOT-3

pwuser162557941033Integrale
Posts: 778Joined: Jul 2021
Mar '23

For Suzuki Cultus AA44S G10B SOHC

Engine Oil: SAE 5W-30 API SF / SG
Quantity: 3.3L with filter
Change Interval: 5,000km or 6 months

Spark Plug: Denso W20EP-U, NGK BP6ES

Coolant: Suzuki Long Life Coolant
Quantity: 3.9L including reservoir tank, 1.0L reservoir tank
Change Interval: 40,000km

Transmission Oil: API GL-4 SAE 75W-90
Quantity: 1.0L drained, 2.4L dry fill
Change Interval: 20,000km

Fuel tank capacity: 40L

Refrigerant: R134a

Brake Fluid: DOT-3
